1000W MPPT Pure Sine Wave Grid-Tie Micro Inverter, Converts 10-30V DC to 110V/120V AC, Perfect for Home Solar or Wind Power Systems

Smart grid tie inverter is a compact unit, which directly converts direct current into alternating current for powering appliances and office equipment and connecting to utility grid. The AC output from Smart micro inverter is synchronized and in-phase with the utility grid. It is a key device of power generation systems such as PV power generation system, wind turbine power generation system.

(1) Allowance 1000W to 1200W big DC power input Specially designed for the current mainstream high-power solar panel.

(2) Unique circuit design, choice of import industrial electronic components, higher efficiency, more stable performance.

(3) Creative MPPT technology, efficiency more than 90%, faster and more sensitive reaction, more reliable.

(4) Modular design, flexible combination and strong system expand- ability.

(5) Adopting high-frequency isolation transformer type, high efficiency, and high security.

(6) Perfect electrical protection function.

(7) Aluminum alloy housing, not rust, heat-resisting and cold-resistant as well as anti-corrosion.

(8) Getting electronic circuit design, appearance design and other core technology patents.

This inverter can provide a output of 1000W, which is sufficient for most household appliances. When the appliances are not in use, the inverter can also supply power to the grid, reducing your electricity bill.

The conversion rate of ≥90% ensures that power is not greatly consumed during the conversion process. What's more important is the pure sine wave electric output, which can protect the appliances to the greatest extent and extend their service life.

Smart micro inverter specially optimized design to work with DC power supplies Vmp>=18V (36 cells) mono-crystal and/or Poly crystalline solar panels, wind turbines. Smart micro inverters are stabilization, reliable and high conversion efficiency items. It is the best choice for PV power generation.

Micro inverters have a smaller size and strong performance, making installation convenient and providing you with a good experience.

Max AC output1000WDC input range10-30VDC MAX input1200WMPPT Voltage18-21VDCMatch AC Grid voltage120V(90-140VAC)/60HzMax Current62.5A(DC Input) /9.1A(AC output)Power Factor>97.5%ProtectionIs-landing; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature ProtectionCertificateCE, ROHS, FCCSize39.5x21x11.5CM

Mars Rock Technology was founded in 2006 and is a company specializing in the research and manufacturing of solar grid connected, energy storage systems, and intelligent charging piles

New energy enterprises with smart energy management solutions.

Why You Chosse This Inverter

Matching solar panels

11*2.2*5inches
