EPEVER Latest MPPT 40A Solar Charge Controller, 12V/24V TRIRON 4210N Intelligent Modular-Designed Regulator with Software Moblie APP - Updated Version of Tracer A/an Series

The TRIRON N series controllers are modular-designed MPPT solar controller.

With the advanced MPPT control algorithm, TRIRON N seriescontrollers can minimize the maximum power point loss rate and losstime, quickly track the maximum power point of the PV array and obtainthe maximum energy from solar modules under any conditions.

With the adaptive three-stage charging mode based on adigital control circuit, TRIRON N series controllers can effectivelyprolong the life cycle of batteries, significantly improve the systemperformance and support all-around electronic protection functions,minimize damages to components of the system caused by incorrectinstallation or system failure at the utmost, and effectively ensuresafer andmore reliable operation of the solar power supply system for alonger service time.

Power Modules

The Power Modules control PV battery charging & loaddischarging without any without any display or interface modulesinstalled they can operate on their own.

If a display or interface module is installed, it will bepowered by the Power module and the appropriate module driver will beloaded.

NOTE: The power module can be operated independently without any other modules.

• NOTE:While wiring the controller do not close the circuit breaker or fuseand make sure that the leads of "+" and "-" poles are connectedcorrectly.
• NOTE: A fuse whichcurrent is 1.25 to 2 times the rated current of the controller must beinstalled on the battery side with a distance from the battery notgreater than 150 mm.
• NOTE: Ifan inverter is to be connected to the system, connect the inverterdirectly to the battery, not to the load side of the controller.

• Package list:
• 1 x Solar Charge Controller
• 1 x User Manual

You can directly contact SolaMr to select for you.



The control you will purchase must meet two conditions

1. The rated current of the controller must be greater than (the power of the solar panel divided by the voltage of the battery)

2. The open circuit voltage of the controller must be greater than the open circuit voltage of your solar panel, and both must be greater than the voltage of your battery

How to choose a solar controller with the appropriate specifications?
