TEMCo 100ft 12 AWG Red Solar Panel Extension Cable with M-F Solar Connector Ends Qty:2

Lifetime warranty. Don't choose a product that will degrade or fail before your panels do. MADE IN THE USA
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    2 lengths of 100 ft. each. UL 4703 rated cable is superior to USE-2 in regards to low temperature flexibility, sunlight resistance, and flame resistance. PV wire for solar panels also has a thicker jacket and insulation than USE-2 wire. USE-2 cable is used in grounded PV systems only, which UL 4703 cable can be used for both grounded and ungrounded arrays. Used for solar panels, DC circuits, and inverter wiring. Silver-plated Copper Terminals outlast and outperform tin-plated models.

    Connectors rated for 35 amp 1000v, 12 AWG wire rated for 31 amps
    Test voltage: 6 kV (50 Hz), PC/PA Insulation
    -40°C ~ 85°C
    IP67 Protection Grade, Safety class II, Flame class UL94-V0
    Contact resistance: Less than or equal to 5 mOhm
    Insertion force: Less than or equal to 50N
    Withdrawl force: Greater than or equal to 50N
    Snap-in locking system

    Wire: 10 AWG
    Nom. outside diameter 0.28"
    19 strands per conductor
    Bare copper conductor
    Cross linked Polyethylene (XLP) insulation
    Max. amps per conductor 40 A, Max. voltage 600 V, -40°C to 90°C
    Type USE-2 per UL 854, RHH/RHW-2 per UL 44, Type PV per UL 4703
