640W Solar Wind System with 12V/24V MPPT Hyrbid Charge Controller: 2pcs 120 Watt Monocrystalline Solar Panel + 400W Wind Turbine Generator + Z Brackets +Cables

This 640w Solar Wind Hybrid Complementary System charge 12v or 24v battery, Solving the pure solar panel system low efficiency problem in low temperature and strong wind.help you to generate power for remote areas in all seasons and save energy.
120w monocrystalline solar panel, withstand high wi
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    NOTES:

    1.Please tell us you need which specification of Power inverter: USA: 110V / EU: 220V / AU: 240V. otherwise we will ship according to your country.

    2.The controller is 12V/24V autodetect, please connect the battery to the controller firstly, and then connect the solar panel and wind turbine with the controller

    3. Solar Kit might be sent in separate packages.


    The Giosolar 640W solar kit includes:

    - 2x 120W Monocrystalline solar panel attached with 90mm of solar cable and waterproof connectors
    - 1x 400W Wind Turbine Generator
    - 1x Solar Wind Hybrid MPPT Charge Controller
    - 1x 5M solar cable with connectors ( Red about 2.5M, Black about 2.5M)
    - 1x 3M battery cable with alligator clip (red about 1.5m, black about 1.5m)
    - 2x Z Mounting Brackets Set
    - 1 Pair of Y Branch Connectors


    120W Mono Solar Panel Specifications:

    -Maximum Power: 120W
    -Optimum Operating Voltage(Vmp): 18V
    -Open Circuit Voltage(Voc): 21.2V
    -Optimum Operating Current (Imp):6.67A
    -Short-Circuit Current (Isc): 7.23A
    -Dimensions: 1015*670*30mm/39.96*26.38*1.18inch
    -Weight: 15.5 lbs(7KG)
    - 90mm of special cable with male & female connectors attached

    400W Wind Turbine Specification:

    Nominal Voltage: DC 12-24V
    Cut-in Wind Speed: 2.5m/s
    Rated wind speed: 10.5m/s
    Maximum Wind speed:35m/s
    Rotor diameter: 1.2M
    Tower diameter: Suggest more than 48mm
    Altutude of towe: 4.5M-10M
    Net weight: 17.64Ibs (8kg)
