1000W Vertical Axis Wind Turbine, 12V 24V AC with Controller Efficient Wind Generator for Home Camping & Boat Use(3 Blades)
2. SUPERIOR PERFORMANCE: The generator is designed with a 3 phase AC permanent magnetometer and has a low torsion, high power trac
-
Detail
SPECIFICATIONS:
Blades quantity:3 Blade
Rated power(W):1000W
Rated voltage(AC):12V/24V/48V/220V
Rotor Diameter of Blades(m):0.55m
Blades height(m):0.75m
Product assembly weight (Kg):<12KG
Started wind speed (m/s):2 m/s
Cut-in wind speed (m/s):3 m/s
Rated Wind speed (m/s):10 m/s
Safe wind speed (m/s):≤40m/s
material:Galvanized aluminum alloy
Generator:Three phase permanent magnet suspension motor
Control System:Electromagnet
Mount Height(m):2- 12m
Generator protection grade:IP54
Altitude:≤4500m
Overspeed protection:Electromagnetic brake Overload
protection:Electromagnetic brake and the unloading unit
Package List:
1 x Main Shaft
3 x Fan Leaf
6 x Holder
2 x Hex Wrench
1 x Instruction
1 x Controller
1 x Iron Plate
1 x Large Screw Kit (4 x Big Screw, 4 x Big Nut, 8 x Big Washer, 4 x Big Gasket)
1 x Middle Screw Kit (13 x Middle Screw, 14 x Middle Washer, 14 x Middle Gasket)
1 x Small Screw Kit (27 x Small Screw, 28 x Small Gasket) -
