1200W-2000W Vertical Axis New Energy Tulip Wind Turbine 12V/24V Breeze Start Power Generation System Wind and Solar Complementary Power Supply System (Color : Orange, Size : 2000W)
High-quality materials: high-quality aluminum alloy blades, the surface is sprayed or oxidized, a
-
Detail
Specification:
Model: 1200W
Rated voltage: DC12V/24V
Blade height: 1.1m
Machine height: 1.25m
Fan rotation diameter: 0.52m
Generator type: Three-phase AC permanent magnet
Blade material: Composite material
Blade bracket: 3 layers
Package size: L1140mm* W530mm*H375mm
Model: 1500W
Rated Voltage: DC12V/24V
Blade Height: 1.1m
Overall Machine Height: 1.25m
Fan Rotation Diameter: 0.52m
Generator Type: Three-phase AC Permanent Magnet
Blade Material: Composite Material
Blade Bracket: 4 Layers
Package Size: L1140mm* W530mm*H375mm
Model: 2000W
Rated voltage: DC12V/24V
Blade height: 1.1m
Machine height: 1.25m
Fan rotation diameter: 0.52m
Generator type: Three-phase AC permanent magnet
Blade material: Composite material
Blade bracket: 4 layers
Package size: L1140mm* W530mm*H375mm
Special control principle: use of wind speed range. A special control principle is adopted to expand its suitable operating wind speed range to 2.5~25m/s, and to maximize the use of wind resources while obtaining a larger total power generation and improving the economy of wind power equipment.
packing list:
1*wind generator
1*User Manual -
