1000W Vertical Wind Turbine Wind Generator, 3 Blades 12V 24V 48V No Noise Wind Turbine Generator with MPPT Controller for Home Ship(220V)

☆ It is perfect wind turbine generator for green windmill, homes energy supplementation! Fit for boats, gazebos, cabins or mobile homes,etc;
☆ Connect the wind turbine's cable to the controller and the battery must be connected to the controller before wiring
☆ If you have not received the ins
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    Specification:
    Wind installation pole size: 60mm
    Number of leaves: 3 leaves
    Wind wheel diameter: 520mm
    Blade height: 750mm
    Rated power (W): 1000W
    Rated voltage (AC): 12V/ 24V /48V /220V
    Initial wind speed (m/s): 2 m/s
    Cut-in wind speed (m/s): 3 m/s
    Rated wind speed (m/s): 10 m/s
    Safe wind speed (m/s): ≤40m/s
    Blade material: galvanized aluminum alloy
    Generator: Three-phase permanent magnet levitation motor
    Control system: electromagnet
    Wind turbine installation height (m): 2-12m
    Generator protection class: IP54
    Working environment temperature: -25~+459C
    Working environment humidity: ≤90%
    Altitude: ≤4500m
    Overspeed protection: electromagnetic brake
    Overload protection: electromagnetic brake and unloading device
    Packing size: 86×38×21cm
    Package weight: 12kg

    packing list:
    3 × pcs blade
    1 × generator
    1 × bolt and nut
    1 × Spindle and arm
    1 × wind controller
    1 × MPPT Hybrid Controller
    1 × English installation manual
