Micro Grid Tie Inverter 2800W for Solar Panel System Single Phase 120V

INDEPENDENT CONTROL: Microinverters can independently control each component in parallel to minimize hazards, you can use with confidence
ACCURATE DISPLAY: Solar grid tie micro inverter built in accurate meter, you can see the working status of individual components, more clear and
HIGH POWER:
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    Spec:

    Item Type: Solar Grid Micro Inverter
    Model: GT-2800W
    Material: Aluminum alloy
    Input Data(DC, PV):
    Number of Input Connectors: 4 Sets
    MPPT Voltage Range: 22V-48V
    Operating Voltage Range: 18-60V
    Maximum Input Voltage: 60V
    Startup Voltage: 22V
    Maximum Input Power: 2800W
    Maximum Input Current: 4 x 16A
    Output Data(AC):
    Rated Output Power: 2800W
    Maximum Output Power: 2800W
    Rated Output Frequency: 50Hz/60Hz
    Default Output Frequency Range: 50Hz: 47.5Hz-51.5Hz, 60Hz: 58Hz-61Hz
    Power Factor: >0.99%
    Total Harmonic Distortion: THDEfficiency:
    Efficiency: 95%
    Standard MTTP Efficiency: 99.5%
    Night Consumption: Mechanical Data:
    Operating Temperature Range: -40℃ to +65℃
    Storage Temperature Range: -40℃ to +85℃
    Water Proof Level: IP66

    Package List:
    1 x Inverter
    1 x Supply Cord
    2 x Screws
    2 x Nuts
    3 x Washers
    1 x Antenna
    1 x User Manual
    1 x Grounding Screw

    1. Maximum Power Output] Achieve power point tracking for maximizing overall output power and improving work efficiency.
    2. Remote Monitoring] Operate and monitor via mobile app for enhanced efficiency, remote upgrades, and fault diagnosis.
    3. Efficient Power Control] Microinverters independently control each component to minimize hazards for and performance.
    4. Flexible Installation] Install directly behind the module or on a bracket for easy maintenance, providing versatile placement options.
    5. Accurate Working Status] Built-in meter allows easy monitoring of individual components, ensuring clear and
