220V,HYZHANHONG 1500W MPPT Charge Controller Wind Turbine DC 12V 24V 48V 220V Low Wind Speed Voltage Regulator for Wind Turbine Solar System (Black)
220V,HYZHANHONG 1500W MPPT Charge Controller Wind Turbine DC 12V 24V 48V 220V Low Wind Speed Voltage Regulator for Wind Turbine Solar System (Black)
✔ 12V/24V/48V controller: The wind turbine controller has 12V/24V/48V and can control 1500W wind turbines. Low power consumption, with short circuit, overload, anti-reverse connection protection, full charge, over-discharge automatic shutdown, recovery and other protection measures. It provides maxi
Quantity
-
Detail
Specifications:
Color: Black
Battery rated voltage: 12V/24V/48V/220V
Wind rated power: 1500W
Protection level: IP67
Size: 10.5*9cm
Weight: 255g
Packing list:
1 x controller
Wiring:
1. Connect the "+" and "-" of the battery to the positive and negative poles of the controller battery.
2. Connect the three-phase output voltage of the wind turbine to the three-phase voltage input terminal of the controller fan.
3. When manual braking is required, short the red thin wire to the positive pole of the battery to complete the manual braking function. To cancel this function, just disconnect the thin red wire. -
