48v,HYZHANHONG 4000W Wind Solar Hybrid Charge Controller 12V 24V 48V MPPT Wind Solar Hybrid Boost Controller for Wind Turbine Generator Charger Battery
✔ [Intelligent Stability]: Perf
-
Detail
Product specifications:
Product type: wind-solar hybrid controller
Material: aluminum alloy
Rated system voltage: 12V, 24V, 48V
Controller size: 16.7*14.5*6.18cm
Packaging size: 36*25*12cm
Net weight: 2.35kg
Gross weight: 2.85kg
Maximum input voltage: wind turbine ≤80V
No-load current (DC): ≤0.05A
Cooling method: aluminum profile heat dissipation and self-cooling
Working temperature relative humidity: -25℃~+80℃ /0~90%, no condensation
Controller power supply: battery or solar energy
Control mode: wind turbine MPPT boost charging, PWM unloading, PWM overcurrent limiting function
Features:
1. Fan charging, intelligent MPPT boost control.
2. Stepless PWM fan discharge, external discharge device, solar intelligent power-off charging.
3. Controller dual power supply function: battery + solar energy.
4. Different load output working modes can be set. High power, stable chip control.
5. The internal circuit board of the controller is sprayed with three anti-paints, dust-proof, moisture-proof and anti-static.
Packing list:
1*Controller
1*Unload load
1*Wire -
