Home / 5000W-8000W 12V 24V Low Speed Gearless Permanent Magnet Generator AC Alternators Use for Wind Turbine Water Turbine(with Base)

5000W-8000W 12V 24V Low Speed Gearless Permanent Magnet Generator AC Alternators Use for Wind Turbine Water Turbine(with Base)

▶Low speed direct drive, no torque ripple.
▶Compact structure, high volume to power ratio.
▶Due to no iron loss, low heat generation and low temperature rise.
▶The generator has a simple structure and is easy to install.
▶Adopting a brushless structure, maintenance free.
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    Specification:
    color: White
    Rated Power: 5000W-8000W
    Rated Voltage: 12V 24V 48V 220V (optional)
    Rated Speed: 400rpm
    Rated Frequency: 50Hz

    Material:
    Spindle and housing:Carbon steel
    Magnetic steel:Rare earth neodymium iron boron material
    Others:
    Efficiency:≥85%
    Working temperature rise:≤70℃
    Operation Temperature:-40℃ — 120℃
    Lubrication Method: Filling Grease
    Service life:≥20 Years
    Weight: 4.5kg

    product content:
    1 x motor with base

  • Customer Reviews
    No comments
