16000W 220V Windmill for Wind Solar Hybrid System, 12V-220V Vertical Axis Wind Generator with MPPT Controller Maglev Wind Turbine Generator

★Safe Design:Vertical blade design,Integrated molding, so there is no risk of a blade flying off, highly increasing the security.coefficient
★360 Degree Wind Available:Vertical wind turbine need not to track the wind. So it can adapt to all wind directions and wind speed. The efficiency of wind u
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    Features:

    A location with no shade around and high terrain, or by the sea, should be chosen, and the installation location should be as high as possible.
    ● Can be installed at the ridge
    Take advantage of the speed increase effect on the hill
    ● Avoid obstructions
    Wind turbine should avoid the shade, and the distance from the shade, should be more than 10 times the height of the shade. Avoid the turbulence area above and below the cliff.
    ● Installed in high place
    The higher the installation position is, the higher the wind speed is.

    Wind Turbine Specifications:
    Started wind speed (m/s):1.5m/s
    Cut-in wind speed (m/s):3m/s
    Rated Wind speed (m/s):11m/s
    Rated voltage(AC):12V/24V/48V/220V
    Rated power(W):16000W
    Safe wind speed (m/s):≤40m/s
    Blade material:glass/ basalt
    Generator:Three phase permanent magnet suspension motor
    Control System:Electromagnet
    Mount Height(m):7-12m (9m)
    Generator protection grade:IP54
    Work environment temperatur:-50~ +60°C
