MPPT Wind Turbine Charge Controller, 48V Aluminum Shell, IP67 Waterproof - Automatic Braking Protection, Display Voltage Current Power, for 1000W Wind Turbine Generator
【Durable Waterproof Design】: Features an IP67 waterproof aluminum alloy shell, ensuring stable performance in humid and harsh o
-
Detail
Item Type: Wind Turbine Charge Controller
Material: Aluminum Shell
Product Size: Approx. 15.1x13.3x5cm / 5.9x5.2x2.0in
Rated Battery Voltage: 48V
Rated Wind Turbine Power: 1000W
Wind Turbine Braking Voltage: 57.6V
Wind Turbine Recovery Voltage: 52.8V
IP Protecting Grade: IP67
Display: Display Voltage, Current, Power Generation
Display Mode: Led (Light Emitting Diode Display)
Package List:
1 x Wind Turbine Charge Controller
Note:
1.Confirm that the wind turbine output voltage is the same as the rated voltage value of the battery.
2.Connect the wires in the following order, first connect the positive and negative poles of the battery, then connect the three phase voltage output of the wind turbine.
3.Please connect the battery and wind turbine to the controller in strict accordance with the instructions, reversing polarity or connecting in the wrong position will cause the system to work abnormally, and even cause damage to the controller. -
